Factory Selling Directly Compact Design Laminated Tube Filling Sealing Machine

  • Factory Selling Directly Compact Design Laminated Tube Filling Sealing Machine
  • Factory Selling Directly Compact Design Laminated Tube Filling Sealing Machine

Factory Selling Directly Compact Design Laminated Tube Filling Sealing Machine

    Unit Price: 30000~40000 USD
    Min. Order: 1 Set/Sets
    Packaging: Wood pallet
    Transportation: Ocean
    Supply Ability: 100 SETS/MONTH
    Port: NINGBO PORT,SHANGHAI PORT

Basic Info

Model No.: ZXF-1980N

Product Description

Production description


This Automatic Plastic Tube filling and sealing machine is suitable for filling all kinds of pasty and high viscous fluid and for large diameter plastic and composite tubes and then internally heating tubes, sealing and printing lot number and date. It is used in the industries of pharmaceutics, foodstuff, cosmetic and bond and so on.



Application

1. Cosmetic products:Face cream, body cream, washing cream, hand cream etc

2. Food products: Condensed milk, chocolate,mustard,sauce ,ketchup,tomato paste,mayonnaise etc

2. Chemical products: Hair color cream, welding paste,ink, paint ,pigment etc

3. Adhesive products: Instant glue, AB glue,silica gel,anaerobic adhesive, silicon



Main Feature:

1. Compact design and auto tube feed.Driving part fully-closed.


2. Tube washing and feeding marking identification, filling,folding, sealing, code printing and finished product output all conducted by a fully auto control system.


3. Tube washing and feeding conducted pneumatically accurate and reliable.



Technical Parameters

Filling volume:1-400ml/unit(Adjustable)

Filling accuracy:

≤±0.5%

Capacity:

30-65unit/Min,Adjustable

Tube diameter:

10-50mm

Tube length:

80-230mm

Hopper volume:

45L

Power:

80V/220V(Optional)

Machine power:

9KW

Air pressure:

0.4-0.6MPa

Dimensions:

2000x1160x2100mm


1653451597(1) (2)

Workflow:

tube bin (hose container) → automatic tube loading → identification and positioning → hose internal cleaning (option) → filling → tail hot melt → pressing and sealing, typing code → (flat tail) → one folding → two Secondary folding→saddle folding→cutting (printing code on metal tube)→finished product discharge.

1653452282 (2)

1653371952(1)

Src Http Sc02 Alicdn Com Kf Htb1ilmvrpxxxxcaaxxxq6xxfxxxx 200412462 Htb1ilmvrpxxxxcaaxxxq6xxfxxxx Jpg Refer Http Sc02 Alicdn Webp 2

Wenzhou Zoncic Machinery Technology Co.,Ltd

  • 1
  • 2
  • 3
  • 4
 Wenzhou Zoncic Machinery Technology Co., Ltd. was established in 2014, formerly known as Haibin Chemical Machinery Factory, with a history of more than 20 years. It is a high-tech enterprise specializing in the research and development, manufacture and sales of equipment in the pharmaceutical, chemical, food, biological and other industries. It mainly produces CBD extraction, molecular distillation, vacuum drying equipment, fermentation tanks, emulsifiers, granulators, paging machines, packaging machines,sanitary pump ,pipe-fittings etc. Zoncic Machinery has an experienced team of engineers who can conduct technical exchanges with customers in a timely and effective manner and offer the best solution; Zoncic Machinery has a skilled production team that can complete equipment production and inspection on time and guarantee product quality; Zoncic Machinery has a passionate sales team that can maintain close communication with customers 24 hours online to meet customer needs ; Zoncic Machinery has a hard-working installation team that can actively cooperate with customer needs to install and debug equipment on site to ensure equipment operation; Zoncic Machinery has a patient and responsible after-sales team that can deal with customer feedback and solve customer doubts in the first time. Our equipment is exported to Southeast Asia, Europe, the United States and other regions and has been unanimously praised by customers. Our aim is to make our equipment worthy of praise.
